Phù hợp với tất cả định dạng và độ phân giải video mà bạn cần ! Capture từ máy quay , đầu ghi và source live để edit , làm hiệu ứng hoặc thiết kế ứng dụng. Decklink Studio 4K và Decklink 4K Pro tích hợp dual link 12G-SDI , hỗ trợ 2160p60 , chất lượng hình ảnh 4:4:4 , 3D stereoscopic cho việc xử lý hậu kỳ các bộ phim hay chỉnh màu. Có nhiều model Decklink cho bạn dễ dàng có sự lựa chọn phù hợp nhu cầu và kinh phí.
Connections
SDI Video Inputs
2 x 12Gb/s SD/HD/2K/4K. Supports single/dual link 4:2:2/4:4:4. 2D/3D switchable.
SDI Video Outputs
2 x 12Gb/s SD/HD/2K/4K. Supports single/dual link 4:2:2/4:4:4. 2D/3D switchable.
Analog Video Inputs
1 x Component YUV on 3 BNCs switchable to S-Video or Composite. Component supports HD and SD.
Analog Video Outputs
1 x Component YUV on 3 BNCs switchable to S-Video and Composite. Component supports HD and SD.
Analog Audio Inputs
2 Channels of professional balanced analog audio via XLR connectors.
Analog Audio Outputs
2 Channels of professional balanced analog audio via XLR connectors.
Optical Fiber Inputs/Outputs (Optional)
2 x 12Gb/s Optical Fiber.
AES/EBU Audio Inputs
2 Channels unbalanced with sample rate converter.
AES/EBU Audio Outputs
2 Channels unbalanced.
SDI Audio Inputs
16 Channels embedded in SD/HD/2K/4K.
SDI Audio Outputs
16 Channels embedded in SD/HD/2K/4K.
HDMI Video Inputs
HDMI type A connector with support for 2160p60.
HDMI Video Outputs
HDMI type A connector with support for 2160p60.
HDMI Audio Inputs
8 Channels embedded in SD/HD/4K
HDMI Audio Outputs
8 Channels embedded in SD/HD/4K.
Sync Input
Tri-Sync or Black Burst.
Device Control
Sony™ compatible RS422 deck control port. Serial ports TxRx direction reversible under software control.
Computer Interface
PCI Express 8 lane generation 2, compatible with 8 and 16 lane PCI Express slots with HDMI or SDI mezzanine card.
Supported Codecs
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10‑bit 4:4:4.
Software
Software Included
DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Internal Software Upgrade
Firmware built into software driver. Loaded at system start or via updater software.
Physical Installation
PCI Express 8 lane generation 2, compatible with 8 and 16 lane PCI Express slots on Mac OS, Windows and Linux. Mac OS systems require a Mac Pro computer with PCI Express slots. Please check the Support pages to see the full system requirements.
