Image Device |
1/3" 3MOS, 2.2 MP |
Resolution |
1920 x 1080 |
Lens |
22x Optical Zoom Lens |
Minimum Illumination |
0.02 Lux (F1.6, Gain 18dB, 1 second exposure, High Sens mode) |
Built-in Filters |
ND Clear
1/4
1/16
1/64 |
Recording Frame Rate |
720 x 480: 59.94i, 29.97p
720 x 576: 50i, 25p
1280 x 720pN 23.98/29.97
1280 x 720p 23.98/25/29.97/50/59.94
1920 x 1080i 50/59.94
1920 x 1080pA 23.98 1920 x 1080pN 23.98/29.97
1920 x 1080p 23.98/25/29.97/50/59.94 |
Recording Format |
AVC Intra
100/50
Inter
DVCPROHD(except 720p/24p,30p,25p)
DVCPRO50/DVCPRO/DV
|
Memory Card Slot |
2 x Micro P2
1 x P2
1 x SD |
LCD Monitor |
3.5", QHD, approximately 156k dots |
Viewfinder |
0.5" OLED, approximately 1.76 MP resolution |
Input and Output Connectors |
Video Input
Timecode: 1 x BNC
Genlock: 1 x BNC (shared with video out)
Video Output
3G-SDI: 1 x BNC
Video: 1 x BNC (Combo Genlock in/Video out)
Audio Input
Balanced: 2 x XLR
Audio Output
Audio out: 1 x
Headphone out: 1 x |
Power Requirements |
7.2VDC
Uses: VW-VBD58 battery
Compatible: CGA-D54 |
